WindPrint S4000 Dopplor Wind Lidar
Dopplor Wind Lidar is for targeting high-end wind power clients, which can capture the 3-D wind field based on Wind Profile Lidar. This series lidar will boost the offshore wind power and complex site wind farm markets with advanced technology and lower costs.
● To capture real-time wake effects turbine-to-turbine, wind profile and turbulence up to 4 km with high spatial and temporal resolution
● To display 3-D wind field variations instantaneously with high speed data sampling rate
● Unattended and continuous operations in harsh mountainous regions
● Eyes safety, ultra-portable, lower power consumption, quick launch, easy operation
● Modularization design for platform, buoy and vehicle-mounted
Specifications:
|
Model |
Dopplor Wind Lidar |
|
Detection range |
30m ~ 4000m (up to 6 km highest) |
|
Data update |
Up to 0.1s（fastest） (configurable) |
|
Range resolution |
15m/30m/60m (configurable) |
|
Wind speed accuracy |
0.1m/s |
|
Wind speed range |
0 ~ 75m/s |
|
Wind direction accuracy |
0.1° |
|
Scanning features |
PPI: 0~360°, RHI: -20°~200° |
|
Power supply |
AC 220V/ 50Hz |
|
Operating temperature |
-40 ~ +60 ℃ |
|
Operating humidity |
0 ~ 100% |
|
Housing classification LASER Safety Compliance |
IP67 1M IEC/EN 60825-1（ eyes safety） |
|
Data transfer |
Ethernet 1000Base-T、GPRS (optional) |
|
Output data |
|
